HDMI Switch

Update: 2015/12/10      View:
  • Brand:    Coas
  • Type:    HDMI Splitter 1x2C(100m)
  • Order Online
Introduction


HDMI Splitter 1x4 mini

Model No. SP104M

1HDMI High Speed input signal split to 4 HDMI High Speed sink devices


HDCP2.0 compliant

3D and 4K*2K support

Input Port :                             1x HDMI (Female connector )

Out  port :                           4x HDMI ( Female connector )

Input lead Max Length :      for 4K — 7M , for 1080P — 20M
Output Lead Max Length :  for 4K — 7M , for 1080P — 15M
Bandwidth :                          10.2Gbps
Output Resolution :             3840 x 2160@50/60, 480i — 1080P@ 50/60
                                             1080P@24/50/60 , VGA -UXGA
Operating Temp :                 -15°C~55°C/5°F~131°F
Deep Color :                        36bit
Housing :                              Metal
Dimensions :                        117mm(L) x 65mm(W) x 27mm(H)
Weight :
Power Supply Input :           100 -240V — 50/60 MHz ,0.3A max
Power Supply Output :         DC 5V —— 2000mA


Allows you to cascade 4 or more splittersCan be used to create a larger distribution of HDMI signalsSupports HDMI specifications - (Deep color, HD lossless audio formats, and Lip Sync)Supports Dolby Digital, DTS-HD, and Dolby True HD audio formatsFront panel LED indicatorsGives an indication of the presence of input/output signalsCEC pass throughExternal and internal EDID settings
